ClearAir® Heat Pump

Description

The ClearAir heat pump uses electricity to deliver heating with zero site emissions, helping you meet decarbonization goals. With a Coefficient of Performance (COP) greater than 1.0, it supplies more heat energy than the electricity it consumes.

ClearAir® Heat Pump Overview

• Integrated monobloc design simplifies installation, maintenance, and service.
• Outdoor rated and supports mounting on roof or on grade.
• Reciprocating compressor for high pressure, high temperature applications.
• Uses R-513A refrigerant, with 573 GWP and classified A1, complying with strict environmental and safety policies.

Applications

The ClearAir® heat pump can deliver outlet water temperatures up to 176°F (80°C), making it well-suited for high temperature-rated coils, radiators, and terminal units found in many existing buildings, enabling efficient system upgrades without costly equipment replacements.

The ClearAir® AW0320 heat pump is a key component of a scalable system design.

• A single unit is ideal for smaller loads or dedicated applications
• Multiple units can be connected together to scale up capacity, meet larger loads, provide redundancy, and spread out wear.
• Hybrid systems combining ClearAir® heat pumps with boilers ensure backup at peak demand, reducing carbon footprint with no risk to heating reliability

Whether your project is a retrofit, major upgrade, or new construction, the ClearAir® heat pump delivers reliable performance across a wide range of applications—all while reducing your project’s carbon footprint.

ClearAir® Heat Pump Attributes

• Compressor: Reciprocating (single)
• Electrical: 480 V/ 3-phase / 60-Hz
• Emissions (ppm NOx): Zero Emissions
• Nominal capacity: 350 MBH (102.6kW)
• Nominal COP: 2.8
• Outlet water temperature range: 86°F (30°C) to 176°F (80°C)
• Refrigerant: R-513A

Note: All literature and technical data links are from our partners Cleaver-Brooks
